HP / Agilent 6813C Performance AC Power Source, 1750 VA, 300 V, 13 A

The HP/Agilent 6813C is a high-performance AC power source and analyzer that combines power amplification, arbitrary waveform generation, and integrated power analysis in a single instrument. It generates standard and distorted AC waveforms, transient disturbances, and DC power—either standalone or as an offset to AC output. Built-in power analyzer functions eliminate the need for separate multimeters, oscilloscopes, and harmonic analyzers, making it ideal for power supply testing, UPS evaluation, avionics ATE, and power factor corrected equipment characterization.

## Technical Specifications

**Output Power**
• Maximum output power: 1750 VA
• DC power capacity: 1350 W

**Voltage Output**
• AC voltage range: 0 to 300 Vrms
• DC voltage range: +/-425 V

**Current Output**
• AC current (RMS): 13 A
• AC current (peak): 80 A
• DC current (RMS): 10 A

**Frequency**
• Operating range: 45 Hz to 1000 Hz (sine wave with resistive load)
• DC to 45 Hz operation available with specified deratings
• Maximum frequency: 1000 Hz

**Waveform Generation**
• Arbitrary waveform generator with preprogrammed standard waveforms
• Normal and distorted power waveform simulation
• Transient generation for AC line disturbance simulation
• DC offset capability on AC output

**Power Analyzer Capabilities**
• RMS, DC, and AC + DC voltage and current measurements
• Peak voltage and current detection
• Real, apparent, and reactive power analysis
• Harmonic analysis up to the 50th harmonic with amplitude and phase data
• Total Harmonic Distortion (THD) calculation
• Triggered digitized waveform acquisition
• Dual-node measurement via Option 020

**Protection & Safety**
• Overcurrent, overvoltage, overpower, and overtemperature protection
• Output disconnect relays and remote TTL inhibit capability
• Safety Class 1 with protective earth terminal

**Interfaces & Connectivity**
• LAN/LXI Core, USB, GPIB, RS-232

**Environmental**
• Indoor use in installation category II, pollution degree 2
• Maximum relative humidity: 95%
• Operating altitude: up to 2000 m
