The HP/Agilent 70907A External Mixer Interface is a 1/8-width module that extends spectrum analyzer frequency coverage by interfacing external mixers with HP 70000 Series Modular Measurement Systems. This interface converts a 321.4 MHz input IF to 21.4 MHz output, enabling high-frequency measurements from 18 GHz to 110 GHz with HP 11970 series mixers, or up to 325 GHz with compatible external mixers from other manufacturers. The module is slaved to an HP 70900B Local Oscillator and provides LO signal distribution, mixer bias output, and IF input conversion within the modular architecture.
– Technical Specifications
• Form Factor: 1/8-width plug-in module for HP 70000 Series mainframes
• IF Conversion: 321.4 MHz input to 21.4 MHz output
• Frequency Extension: 18 GHz to 110 GHz with HP 11970 series mixers; up to 325 GHz with compatible external mixers
• Control Architecture: Slave module requiring HP 70900 Local Oscillator (firmware 860203 or later)
• Connectors: SMA female (LO IN, LO OUTPUT, IF INPUT, MIXER BIAS OUT)
– Key Features
• LO signal distribution to external mixer via dedicated output
• Mixer bias voltage output for bias-requiring mixer designs
• IF input reception and 321.4 MHz to 21.4 MHz frequency conversion
• ACT (Active) LED indicates keyboard link and module activation status
• ERR (Error) LED signals fault conditions
• Firmware compatibility with HP 70900 LO versions 860203 or later; upgrade kit (70900-60137) available for earlier versions
– Typical Applications
• Microwave and millimeter-wave spectrum analysis
• Extended frequency coverage beyond base analyzer capability
• External mixer integration in modular measurement systems
– Compatibility & Integration
The 70907A integrates with HP/Agilent 70000 Series Spectrum Analyzers and requires an HP 70900B Local Oscillator. Compatible external mixer families include HP 11970 series (18–110 GHz) and third-party mixers rated to 325 GHz. Installation into an HP 70000 Series mainframe is required. Verification procedures are provided in the HP 70907A/B External Mixer Interface Installation and Verification Manual.
