HP / Agilent 8169A Polarization Controller ratio >45 dB (1530nm to 1560nm)

The HP/Agilent 8169A Polarization Controller enables precise synthesis and manipulation of optical polarization states across the C-band and extended L-band. Using zero-order waveplates and a high-performance linear polarizer, it generates all possible polarization states on the Poincaré sphere with ±0.09° accuracy. The instrument supports polarization-dependent loss (PDL) and polarization mode dispersion (PMD) measurement, polarization synthesis in optical research, and telecommunications applications requiring deterministic SOP control.

– Technical Specifications

Optical Performance

• Operating wavelength range: 1400 nm to 1640 nm
• Polarization extinction ratio: >45 dB (1530 nm to 1560 nm); >40 dB (1470 nm to 1570 nm); >30 dB (1400 nm to 1640 nm)
• Insertion loss: 60 dB
• Total reflection (characteristic): >55 dB
• Individual reflections (characteristic): >60 dB

Polarization Control

• Accuracy and repeatability: ±0.09° on Poincaré sphere
• Wavelength dependence: ±0.1°/nm on Poincaré sphere
• Polarization adjustment resolution: 0.18°
• Adjustment methods: Manual front-panel knobs, nine Save/Recall registers, autoscanning across all SOPs
• Transition path specification: Pre-deterministic algorithms along orthogonal great circles

Interfaces & Physical

• Fiber type: Single-mode input/output
• Connector options: Pigtailed fiber (020), straight contact (021), angled contact/APC (022)
• Power: 48 Hz to 60 Hz, 100/120/220/240 V rms (47 to 63 Hz)
• Dimensions: 10 cm H × 42.6 cm W × 44.5 cm D
• Weight: 9 kg

– Key Features

• Zero-order waveplate architecture for low PDL and stable operation
• Poincaré sphere SOP synthesis with deterministic path specification
• Low insertion loss variation ensures stable performance across multiple rotations
• Nine programmable registers enable rapid state-of-polarization switching
• Single-mode pigtailed and connector-based interfaces

– Typical Applications

• PDL and PMD characterization of optical components
• Polarization-sensitive component and system testing
• Optical research requiring full SOP control
• Telecommunications test and measurement

– Compatibility & Integration

Supported by Plug&Play drivers and Photonic Foundations Library software for automated control. Connector adapters (HP 81000XI series) required when selecting straight or angled contact options.
