Inficon / Leybold 230682V01 Graphix Three Universal Controller for Active Vacuum Sensors

The Inficon/Leybold 230682V01 Graphix Three is a universal controller for active vacuum sensors, delivering real-time measurement data across up to three independent channels. The 3.5-inch TFT touchscreen provides graphical curve display, bargraph visualization, and decimal readouts with zoom functionality across a measurement range of 1 × 10⁻¹⁰ to 2000 mbar (0.75 × 10⁻¹⁰ to 1500 Torr).

This controller accepts Leybold’s THERMOVAC, IONIVAC, PENNINGVAC, CERAVAC, and DU sensor series, plus active vacuum gauges from other manufacturers outputting linear or logarithmic 0–10 V signals. The intuitive menu interface supports six independently adjustable switching thresholds with variable hysteresis and floating changeover relay contacts rated 1 A / 30 V AC / 30 V DC. Each channel output can be freely assigned to individual measurement channels.

## Technical Specifications

• Measurement range: 1 × 10⁻¹⁰ to 2000 mbar / 0.75 × 10⁻¹⁰ to 1500 Torr
• Measurement channels: Up to 3
• Display: 3.5-inch TFT touchscreen
• Visualization: Curve display, bargraph display, decimal display with zoom
• Display units: mbar, Torr, micron, Pascal, psi (selectable)
• Switching thresholds: 6 adjustable with variable hysteresis
• Relay output: Floating changeover contact, 1 A / 30 V AC / 30 V DC
• Chart recorder outputs: Three 0–10 V outputs (one per channel); optional 4th programmable output
• Mains: 100–240 V, 50/60 Hz

## Key Features

• Data logging via front-panel USB for measurement data and configurations
• Pressure rise test function for leak detection
• Degas function for ITR transmitters; zero alignment for CTR transmitters
• Sensor connections: 15-way Sub-D socket and FCC68 (RJ45)
• RS 232 and RS 485 communication interfaces
• Multi-language support: English, German, Chinese, Japanese, French, Italian, Spanish, Korean

## Compatibility & Integration

• Leybold THERMOVAC, IONIVAC, PENNINGVAC, CERAVAC, and DU sensor series
• Third-party active vacuum gauges with 0–10 V linear or logarithmic output
• Standalone or rack-mountable operation
• USB data transfer for real-time measurements and configuration management
