Infrared Camera Inc. T-Cam 160 P

The T-Cam 160 P is a handheld thermal imaging camera designed for professional diagnostics and inspection work. It combines a 160 × 120 pixel microbolometer detector with a visible light camera to deliver synchronized infrared and optical imagery. The device operates across the 8 μm to 14 μm spectral band with 80 mK thermal sensitivity, 50 Hz frame rate, and 14-bit dynamic range. A 3.5″ capacitive touchscreen displays thermal data with continuous 1× to 20× digital zoom, voice and text annotation, and multiple color palettes. The T-Cam 160 P measures temperature from −20 °C to 150 °C (±2 °C accuracy) with optional extended range to 400 °C. Image capture includes spot, line, and area measurement tools. Video recording supports MP4 format at 640 × 480 resolution, 30 fps, with storage capacity exceeding 60 minutes. Battery runtime reaches approximately 4.5 hours on a single charge.

## Technical Specifications

• **Infrared Detector:** 160 × 120 pixel microbolometer array; 17 μm pixel pitch; 8 μm to 14 μm spectral band; 80 mK thermal sensitivity (NETD); 50 Hz frame rate; 14-bit dynamic range; >99% pixel operability
• **Optics:** 9 mm manual focus lens; 17° × 17° field of view; 0.2 m minimum measurement distance
• **Temperature Measurement:** −20 °C to 150 °C range; ±2 °C accuracy; 2 lines, 3 area boxes, 3 spot measurements
• **Display:** 3.5″ color LCD capacitive touchscreen; 320 × 240 pixel resolution; IR, visible, and fused image modes
• **Digital Imaging:** 1× to 20× continuous zoom; JPG image format; MP4 video at 640 × 480, 30 fps; voice and text annotations up to 60 seconds; white hot, black hot, iron, rainbow, and feather palettes
• **Visible Camera:** 640 × 480 pixel resolution; LED flashlight
• **Power:** DC 9 V to 12 V input; rechargeable Li-Po battery; ~4.5 hour operation; intelligent charger included
• **Storage:** MicroSD card compatible

## Key Features

• Dual thermal and visible imaging with real-time fusion display
• 14-bit radiometric data capture for precise temperature analysis
• Touch-driven interface with multi-point measurement capability
• Extended temperature range option (0 °C to 400 °C)

## Typical Applications

Building envelope diagnostics, electrical distribution inspection, HVAC system analysis, food service temperature monitoring.

## Compatibility & Integration

MicroSD card storage; MP4 and JPG file formats support standard post-processing workflows.
