Innocor Test Point TS-30 with JDSU N530-130 Board

The Innocor Test Point TS-30 with JDSU N530-130 Board is a modular chassis platform for network testing and performance validation across multiple data rates and protocols. The TS-30 provides three slots for hot-swappable test modules, supporting configurations from 1 Gbps to 40 Gbps and OC-192/STM-64 channelized SONET/SDH testing. The N530-130 board enables comprehensive Layer 1, 2, and 3 diagnostics with traffic generation, filtering, bit error rate testing, and error insertion capabilities. Web browser control with Java plug-in support ensures operator accessibility across test environments.

– Technical Specifications

-# Chassis (TS-30)

• Slots: 3 modular slots
• Hot Swappability: Supported for all modules
• Power Input: 110 V / 220 V, 50 Hz / 60 Hz
• Operating Temperature: 0°C to +35°C
• Control Interface: Web browser with Java plug-in capability

-# JDSU N530-130 Board

• Data Rates: Channelized SONET/SDH from OC-768/STM-256 down to STS-192c/VC-4-64c; 10 Gbps and 1 Gbps rates
• Optical/Electrical Interfaces: 10 Gbps support on FC, SC, ST, LC, and DIN connectors
• Traffic Generation (Layer 2): Constant, Bursty, Ramp, Flood modes; configurable MAC addresses, frame format, VLAN tags, frame length (including Jumbo and Undersized), utilization percentage, pause frames
• Traffic Generation (Layer 3): Configurable IP source/destination, DNS settings, TOS, TTL, packet length 34–1500 bytes; Ping and Traceroute support
• Traffic Filtering (Layer 2): MAC address filtering, frame type/length, VLAN tagged/untagged frame selection
• Traffic Filtering (Layer 3): IP address filtering, TOS/DSCP type selection
• BERT Patterns (Layer 1): IEEE 802.3 and NCITS TF-25 standard patterns including High/Low/Mixed Frequency Test, RPAT, JTPAT, SPAT
• BERT Patterns (Layer 2): PRBS (2^23-1, 2^31-1, inverted), All 1s, All 0s, User-defined; Long Continuous Random and Contiguous Jitter Test Patterns
• Additional Capabilities: Error insertion, Service Disruption Time Measurements, automation and scripting, LAN interface via Controller Module

– Key Features

• 3-slot architecture supports multiple module types: 1 Gbps, 10 Gbps, 40 Gbps, Multi-rate, OC-192/STM-64, and Group Controller modules
• Pseudo Random Binary Sequence (PRBS) pattern generation
• Service Disruption Time Measurements for network availability analysis
• Multi-layer diagnostic capability from physical through IP layer

– Typical Applications

• Network acceptance testing and commissioning
• Performance baseline establishment and regression testing
• Protocol and frame format validation
• Error and alarm injection for resilience testing
• SONET/SDH and Ethernet network diagnostics

– Compatibility & Integration

The TS-30 accepts TestPoint family modules and supports LAN-based control through dedicated Controller Modules. Configuration and scripting enable integration into automated test workflows.
