ISO-Tech IPS2010

The ISO-Tech IPS2010 is a 200W programmable switching DC power supply engineered for laboratory and educational bench-top applications. It delivers adjustable output voltage (0–60VDC) and current (0–10A) with selectable constant voltage (CV) and constant current (CC) operating modes. The unit incorporates multi-layer protection: over voltage limit (OVL), over current limit (OCL), over temperature protection (OTP), and over power limit (OPL). A large backlit LCD panel displays real-time output and parameter values. The key lock function prevents accidental setting drift, while three-step fan speed control manages thermal load dynamically.

## Technical Specifications

**Electrical Performance**
• Output voltage range: 0–60VDC
• Output voltage resolution: 20mV (0–60VDC); 10mV (0–40VDC and 0–20VDC ranges)
• Output voltage program accuracy: ±0.05% reading + 4 digits
• Output current range: 0–10A
• Output current program accuracy: ±0.05% reading + 3 digits
• Readback voltage accuracy: ±0.05% reading + 4 digits
• Readback current accuracy: ±0.1% reading + 5 digits
• Input: 115/230VAC ±15%, 50/60Hz
• Maximum power consumption: 420VA

**Protection & Thermal Management**
• Over voltage, over current, over temperature, and over power limiting
• 3-step fan speed control for optimized cooling efficiency

**Construction & Compliance**
• VDE 0411 (EN 61010) standard compliance
• Class A EMC device; meets European and national directives
• 4mm safety sockets for output connections (negative, positive, earth)

## Key Features

• Large backlit LCD display for voltage and current monitoring
• Dual operating modes with CV/CC indicator lights
• Key lock to prevent unintended parameter changes
• Normal, +%, and −% output operation keys for rapid adjustment
• RS-232C opto-isolated interface for remote programming and control
• AC rear panel power inlet socket

## Typical Applications

• Laboratory power supply for component testing and verification
• Educational demonstration and student training
• General bench-top DC power requirements

## Compatibility & Integration

RS-232C interface enables integration with automated test systems and remote control applications via standard serial communication protocols.
