JCA Technology JCA1011-383TCA

The JCA Technology JCA1011-383TCA is an RF amplifier module engineered for industrial and technological applications requiring precision signal amplification across microwave frequencies. This electronic component delivers 27 dB of gain with 22 dBm output power across the 6–11 GHz band, making it suitable for test equipment, automation systems, and advanced electronic installations. The module is housed in a compact metal enclosure consistent with the JCA10 series form factor.

## Technical Specifications

• Frequency Range: 6–11 GHz
• Gain: 27 dB
• Output Power: 22 dBm
• Physical Packaging: Metal case, 25.4 × 20.3 × 10.2 mm (1.0″ × 0.8″ × 0.4″)

## Key Features

• Fixed gain architecture optimized for microwave band operation
• Compact metal housing for thermal management and EMI containment
• Integrated design suitable for OEM integration into larger RF systems

## Typical Applications

• RF test and measurement systems
• Microwave signal conditioning circuits
• Industrial control and automation electronics
• Advanced electronic subsystems requiring precision amplification

## Compatibility & Integration

The JCA1011-383TCA follows the mechanical and electrical conventions of the JCA10 component family. Integration into multi-stage RF chains and measurement architectures benefits from its standardized 25.4 × 20.3 × 10.2 mm housing. Specific interface pinouts, mating connectors, and mounting provisions should be confirmed against application requirements.
