JDS Uniphase MAP200-MLCS-A2112B-M100-MFA

The JDS Uniphase MAP200-MLCS-A2112B-M100-MFA is a 1×12 single-mode fiber optical switch module designed for the MAP-200 modular test and measurement platform. This FC/APC bulkhead-equipped switch operates across the 1270 nm to 1670 nm wavelength range with maximum insertion loss of 1.2 dB and supports both sequential and random switching operations. The module integrates into MAP-200 mainframe chassis—available in three-slot benchtop or eight-slot 19-inch rack configurations (3 RU high)—enabling flexible optical network component and system testing in laboratory and manufacturing environments.

## Technical Specifications

• **Switch Configuration:** 1×12 single-mode fiber switch
• **Connector Type:** FC/APC bulkhead
• **Wavelength Range:** 1270 nm to 1670 nm
• **Fiber Type:** Single-mode (SM) 9/125 µm
• **Insertion Loss (without connectors):** Maximum 1.2 dB
• **Polarization Dependent Loss (PDL):** Maximum 0.08 dB
• **Return Loss:** Greater than 45 dB
• **Repeatability (sequential switching):** ± 0.03 dB
• **Repeatability (random switching):** ± 0.08 dB
• **Switching Time:** 25 ms for first channel; 15 ms for each additional channel

## Key Features

• Hot-swappable instrument cassette design for maintenance without system downtime
• Field-replaceable power supply module
• Benchtop feet with rubber accents for stability and vibration isolation
• 3 RU height across all chassis configurations

## Typical Applications

• Optical network component testing
• Optical system validation
• Manufacturing test and characterization

## Compatibility & Integration

The MAP-200 platform supports LXI compliance with Ethernet connectivity, GPIB, SCPI-compliant remote commands, and optimized IVI drivers for LabVIEW, Visual C++, Visual Basic, and LabWindows. Optional 10.4-inch touch-screen display module (MAP-200KD) and DVI external display connectivity available. USB device ports support external peripherals.
