JDS Uniphase MAP200-MOSW-C121C004BM-M101-MFP

The MAP200-MOSW-C121C004BM-M101-MFP is an optical switch module for the JDS Uniphase MAP-200 platform, designed to route and manage optical signals in test and measurement applications. This hot-swappable module integrates into the MAP-200 mainframe to enable signal path control with high reliability and low insertion loss, supporting laboratory and manufacturing test environments requiring precise optical switching and repeatability.

## Technical Specifications

• **Platform:** JDS Uniphase MAP-200 mainframe
• **Module Type:** Optical Switch Module
• **Switch Durability:** Over 100 million switch cycles without specification degradation
• **Performance:** low insertion loss and high repeatability for measurement accuracy
• **Form Factor:** Module for 3 RU MAP-200 chassis (three-slot or eight-slot 19-inch rack configurations)
• **Hot-Swappable:** Yes—install or remove while system is powered on

## Key Features

• Efficient optical signal routing and management within test setups
• High-cycle durability ensures measurement repeatability across extended testing campaigns
• Hot-swappable architecture minimizes system downtime during module replacement or upgrades
• Compatible with multiple fiber types and connector options supported by the MAP-200 platform
• Integrates with the MAP-200 modular backplane architecture

## Typical Applications

• Insertion loss and return loss measurement
• Optical signal conditioning and routing
• High-cycle switching applications requiring measurement repeatability
• Laboratory and manufacturing test environments using modular optical platforms

## Compatibility & Integration

**Control Interfaces:** The host MAP-200 mainframe supports GPIB, LXI (Ethernet), and USB. External monitor connection via DVI port and optional 10.4-inch touch-screen display with integrated keypad and scroll wheel for local control.

**Software Integration:** IVI drivers and support for LabVIEW, Visual C++, and Visual Basic development environments.
