JDS Uniphase MAPA+2370290FP

The JDS Uniphase MAPA+2370290FP is a dual-channel optical attenuator module for single-mode fiber networks requiring precise power control across the extended C- and L-band spectrum. This MAP series module delivers attenuation up to 60 dB with 0.01 dB resolution while maintaining 1.5 dB typical insertion loss, making it suitable for telecommunications and photonics test environments where signal integrity and accuracy are critical.

## Technical Specifications

• **Channels:** Dual-channel
• **Fiber Type:** Single-mode (9/125 µm)
• **Wavelength Range:** 1200 nm to 1700 nm
• **Attenuation Range:** Up to 60 dB
• **Attenuation Resolution:** 0.01 dB
• **Insertion Loss:** 1.5 dB (typical)
• **Optical Monitor Port:** Built-in 10-90 port for real-time signal monitoring

## Key Features

• Dual independent channels for simultaneous attenuation control
• Extended wavelength coverage spanning 1200 nm to 1700 nm
• Fine-grain 0.01 dB resolution for demanding measurement applications
• Integrated optical monitor port enables inline signal verification without external tap couplers
• Modular cassette form factor integrates directly into MAP platform chassis
• Remote operation capability via standard instrumentation interfaces

## Typical Applications

• Optical power control in telecommunications and fiber-optic networks
• Signal integrity verification in high-precision optical systems
• Transmission distance extension through managed power level adjustment
• Optical test and measurement requiring calibrated attenuation

## Compatibility & Integration

Designed for the JDS Uniphase Multiple Application Platform (MAP) instrumentation ecosystem. Compatible with MAP Master (MAP+2M00) and MAP Benchtop (MAP+2B00) chassis configurations. Supports standard single-mode connectors and remote control interfaces inherent to the MAP platform architecture.
