JDS Uniphase MAPS+1K70116N3SC

The JDS Uniphase MAPS+1K70116N3SC is an instrumentation cassette module designed for the MAP (Multiple Application Platform) series—a modular optical test and measurement system. This hot-swappable module integrates into either the 19-inch 8-slot Master chassis or the 9.5-inch 3-slot Benchtop chassis, supporting reconfigurable optical test architectures. The cassette operates within the MAP ecosystem’s common backplane infrastructure, enabling field replacement and system expansion without extended downtime.

## Technical Specifications

• **Operating Temperature:** 0 to 50 °C
• **Storage Temperature:** -30 to 60 °C
• **Humidity:** < 80% RH, non-condensing (0 to 40 °C)

## Key Features

• **Hot-Swappable Design:** Field-replaceable cassette architecture integrates directly into MAP chassis via common backplane
• **Modular Platform Compatibility:** Functions within a system supporting over 15 instrumentation cassette types
• **Local and Remote Control:** Accessible via 9-key keypad with color display; remote operation via RS-232 and GPIB interfaces
• **MAP Console Software Support:** Integrates with JDS Uniphase control and automation software

## Typical Applications

The MAPS+1K70116N3SC cassette module serves optical test and measurement applications within the MAP platform, which accommodates specialized instrumentation including optical switching matrices, tunable laser sources, variable attenuators, and erbium-doped fiber amplifiers (EDFA).

## Compatibility & Integration

• Compatible with MAP+2M00 Master chassis (19-inch, 8-slot, 3U)
• Compatible with MAP+2B00 Benchtop chassis (9.5-inch, 3-slot)
• Operates on common hot-swappable backplane architecture
• Remote connectivity: RS-232 and GPIB interfaces
• Field maintenance: All key modules including controller, power supply, keypad/display, and remote interface are field replaceable
