JDS Uniphase OAB 1415-16-Z001 Erbium-Doped Fiber Amplifier

The JDS Uniphase OAB 1415-16-Z001 is an Erbium-Doped Fiber Amplifier (EDFA) engineered to boost optical signal power in fiber optic communication systems across the C-band and L-band wavelength ranges. Operating from 1528 nm to 1610 nm, this amplifier delivers high gain with low noise figure, making it ideal for manufacturing test environments and research applications. The unit supports multiple configurations—pre-amplifier, booster, or in-line amplifier—to match diverse deployment requirements. A benchtop or rack-mountable design with front-panel LCD display provides real-time monitoring of input/output power and current control.

– Technical Specifications

• Wavelength Range: 1528–1610 nm (EDFA window); C-band (1528–1565 nm), L-band, and C+L-band configurations available
• Saturated Output Power: Typically 15–24 dBm depending on configuration and band
• Noise Figure (Maximum): 3.3 dB (C-band pre-amplifier) to 5.5 dB (L-band); 4.5–5 dB typical for C-band booster configurations
• Small Signal Gain (Minimum): 14–37 dB depending on amplifier type and wavelength band
• Spectral Gain Flatness (Maximum): 1.7 dB peak-to-peak (1570–1603 nm, select configurations)
• Polarization Dependent Loss (PDL) (Maximum): < 0.3 dB
• Polarization Mode Dispersion (PMD) (Maximum): 0.6–0.9 ps depending on configuration

– Key Features

• Multiple amplifier topologies optimize performance for signal pre-amplification, power boosting, or in-line applications
• Wavelength coverage spans 1528–1610 nm with dedicated C-band, L-band, and C+L-band options
• Low polarization-dependent loss maintains signal integrity across all polarization states
• Compact benchtop or rack-mountable configuration with LCD front-panel display
• Accommodates single-channel signal input

– Typical Applications

• Optical signal amplification in C-band and L-band communication systems
• Manufacturing test and validation of fiber optic components
• Research and development in long-haul optical networks

– Compatibility & Integration

• Designed for integration into fiber optic test benches and laboratory setups
• Available in multiple configurations to support various system architectures
