The JDSU/AFC SRFA1516 BR1SC-MUX is a dual-band optical multiplexer that combines C-band and L-band signal processing within a single chassis. The unit integrates dedicated EDFA booster amplifiers for both bands, along with multiplexer and demultiplexer functions, enabling simultaneous wavelength division multiplexing across extended spectral ranges. This architecture supports optical add-drop multiplexing and WDM system deployments where C-band and L-band signal conditioning and wavelength separation are required.
– Technical Specifications
Wavelength Coverage:
• C-band: 1530–1565 nm
• L-band: 1565–1625 nm
Integrated Amplification & Multiplexing:
• One C-band EDFA booster module
• One L-band EDFA booster module
• Built-in C/L band multiplexer
• Built-in C/L band demultiplexer
Optical Interface:
SC/PC connectors for signal input and output.
Electrical Requirements:
120 V AC power input.
– Key Features
• Integrated booster amplification eliminates the need for external C-band and L-band amplifiers in dual-band systems
• Combined mux/demux function reduces footprint and cable complexity
• SC/PC optical connectors for standard rack integration
• Manufactured to Telcordia GR-1221 specifications for reliability
– Typical Applications
• Optical add-drop multiplexing (OADM) systems
• Wavelength division multiplexing (WDM) infrastructure
• Long-haul and metro optical networks requiring extended C-band and L-band reach
– Compatibility & Integration
The SRFA1516 BR1SC-MUX is designed for integration into carrier-grade optical transport systems. Components meet Telcordia GR-1221 standards. Available in new condition with manufacturer test data or used condition.
