The JDSU FBP-P6 is a handheld video inspection probe microscope purpose-built for detailed fiber optic connector analysis. Dual magnification (200X and 400X) enables flexible inspection of connector end-faces across varying defect scales. PAL video output integrates with JDSU HD-series displays, Video Output Modules (FBP-VO1, FBP-VO2), or USB converters for PC-based workflows. Coaxial blue LED illumination with 100,000+ hour lifespan delivers consistent, shadow-free imaging critical for identifying contamination, scratches, and surface defects.
– Technical Specifications
• Magnification: 200X, 400X (dual)
• Video Output: PAL
• Sensor: 1/3-inch CMOS
• Field of View (Horizontal): 550 μm @ 200X; 350 μm @ 400X
• Live Image Resolution: 800 × 600 pixels at 15 fps
• Light Source: Blue LED, >100,000 hour lifespan
• Illumination Technique: Coaxial
• Focus Control: Adjustable manual focus (in-probe)
• Video Connector: 4-pin Hirose™ male
• Cord Length: 240 cm (94 inches)
• Dimensions: 140 × 46 × 43 mm (5.5 × 1.8 × 1.7 inches)
• Weight: 180 g (6.35 oz)
• Power: Supplied by connected display device or USB module
– Key Features
• Ergonomic handheld design for single-hand operation in confined spaces
• QuickCapture™ button on select models enables instant image capture
• Adjustable in-probe manual focus for precise end-face alignment
• 1/3-inch CMOS sensor delivers 800 × 600 pixel live images at 15 fps
• Blue LED coaxial illumination eliminates shadows and glint artifacts
– Typical Applications
• Inspection of simplex and multi-fiber (ribbon) connectors
• Male (patch cord) and female (bulkhead) fiber interconnect assessment
• Backside patch panel connector examination
• Transceiver and optical device internal connector verification
• IEC 61300-3-35 compliance testing
– Compatibility & Integration
The FBP-P6 connects via 4-pin Hirose™ male connector to JDSU HD-series analog displays, FBP-VO1/FBP-VO2 Video Output Modules, or third-party USB converters. Compatible with standard bulkhead, patch cord, long-reach, APC, angled, and RibbonDrive™ interchangeable inspection tips and adapters for extended connector coverage.
