Keithley 3323A

The Keithley 3323A is a 2-channel arbitrary waveform and function generator engineered for electronic testing and design applications. It generates sine, square, triangle, ramp, pulse, noise, and user-defined arbitrary waveforms with dual-channel architecture enabling synchronized signal production. Advanced modulation capabilities—including AM, FM, PM, FSK, sweep, and burst modes—support complex test scenarios. An intuitive front panel combined with a high-resolution display provides direct instrument control, while remote programming via standard interfaces enables integration into automated test systems.

## Technical Specifications

**Signal Generation:**
• 2 independent output channels
• Arbitrary waveform generation with dedicated memory for user-defined signals
• Standard waveforms: sine, square, triangle, ramp, pulse, noise
• Modulation modes: AM, FM, PM, FSK, sweep, burst
• Frequency accuracy to ppm-level stability
• High-resolution amplitude and frequency control
• Precise phase relationship control between channels

**Output Characteristics:**
• Wide dynamic range voltage and current capability
• High-resolution output for signal integrity

## Key Features

• Dual-channel synchronized operation for phase-coherent signal generation
• High-resolution display for real-time waveform visualization and parameter monitoring
• Intuitive front panel controls for manual setup and adjustment
• Remote programming and automation capability

## Typical Applications

The 3323A addresses complex signal generation requirements in electronic design validation, component characterization, and production testing environments where multi-channel, modulated signal sources are essential.

## Compatibility & Integration

**Standard Interfaces:**
• GPIB
• RS-232
• USB
• Optional LAN (LXI) for network control and multi-instrument synchronization

**Physical Form:**
Benchtop configuration suitable for laboratory and production settings with standard AC power input.
