Keithley 7016A

The Keithley 7016A is a dual 1×4 multiplexer card delivering independent, bidirectional RF signal routing across two isolated channels. Each multiplexer connects one common port to four selectable inputs, operating from DC to 2GHz with 50Ω characteristic impedance. Designed as a plug-in module for Keithley 7001 and 7002 switch mainframes, the 7016A enables flexible high-frequency signal management in automated test systems requiring repeatable, low-distortion switching.

The card employs Form A relay contacts with 120mA drive current and 8ms actuation time. SMA connectors interface to external circuits; SMB terminator jacks accommodate user-supplied 50Ω loads on unselected inputs to suppress reflections. Contact resistance measures 0.5Ω with 1GΩ with <50pF capacitance.

## Technical Specifications

• **Configuration:** Two independent bidirectional 1×4 multiplexers with isolated grounds
• **Frequency Range:** DC to 2GHz
• **Characteristic Impedance:** 50Ω nominal
• **Maximum Voltage:** 30V (between any terminal/center and chassis)
• **Maximum Current:** 0.5A
• **Maximum Power:** 10VA up to 900MHz; 3VA @ 2GHz
• **Contact Resistance:** 0.5Ω
• **Contact Potential:** <6µV
• **Actuation Time:** 8ms
• **Rise Time:** <200ps
• **Signal Delay:** 1GΩ
• **Isolation — Center to Shield:** >1GΩ, 100MΩ
• **Contact Life:** 3×10⁵ cycles @ 30V/10mA; 3×10⁵ @ 900MHz, 1W; 1×10⁶ cold switching

## Key Features

• SMA signal connectors with SMB terminator jack provisions
• Recommended RG-223/U cable
• Operating temperature range: 0°C to 50°C (35°C @ 80% RH); storage: −25°C to 65°C
• Complies with EU Directive 89/336/EEC (EMC) and 73/23/EEC (safety; EN61010-1/IEC 1010)

## Typical Applications

• High-frequency RF/microwave signal routing
• Multi-channel automated test systems
• Signal path switching in measurement setups demanding minimal insertion loss and phase distortion

## Compatibility & Integration

Plug-in card for Keithley Model 7001 and Model 7002 switch mainframes.
