Keithley 7055-102-02C

The Keithley 7055-102-02C is a shielded, high-density cable engineered for Keithley switching systems. It delivers noise-minimized connections for sensitive measurements by employing shielded construction to reduce electromagnetic interference. The cable interfaces with the Keithley 7055 Screw Terminal Card, which serves as the signal interface for the 7056 General-Purpose Scanner Card, enabling flexible relay switching configurations across multiple channels.

## Technical Specifications

This shielded, high-density cable is optimized for low-noise signal transmission in measurement applications. The cable connects to screw terminal connectors on the 7055 Screw Terminal Card, facilitating quick-disconnect capability for system reconfiguration and maintenance.

## Key Features

• Shielded construction minimizes noise and interference for sensitive measurements
• High-density design for compact integration
• Compatible with Keithley 7055 and 7056 switching system architecture
• Supports both 1-pole and 2-pole channel configurations when paired with the 7055/7056 system
• In 1-pole mode, independent HI and LO channels operate in isolation, effectively doubling available input channels

## Typical Applications

The 7055-102-02C cable is suited for precision relay switching, data acquisition systems, and automated test environments where noise rejection and channel isolation are critical. Its use with the 7056 Scanner Card makes it ideal for multi-channel switching applications requiring configurable topology.

## Compatibility & Integration

This cable is designed specifically for the Keithley 7055 Screw Terminal Card and the 7056 General-Purpose Scanner Card. It integrates into larger Keithley switching systems, providing the interconnect layer between external equipment and the scanner card’s relay switching matrix. The 7055/7056 combination supports flexible wiring for 2-pole standard operation or 1-pole independent operation on each channel.
