Kepco BOP500M

The Kepco BOP 500M is a high-voltage bipolar operational power supply and amplifier engineered for precision applications requiring both sourcing and sinking capability. It operates in voltage-stabilizing or current-stabilizing modes with independent control channels for local or remote operation. The Class A output stage delivers bidirectional response from zero, ensuring linear transitions across the full rated voltage and current ranges with no polarity switching.

## Technical Specifications

**Electrical Performance**
• Output Voltage: ±500 V DC
• Output Current: ±80 mA DC
• Power Output: 40 W
• Input Power: 105–125 V AC or 210–250 V AC, 50–65 Hz (front panel selectable)
• Power Consumption: Approximately 250 W
• Power Factor: 0.8
• Operating Temperature: -20°C to +65°C
• Storage Temperature: -40°C to +85°C

**Output Characteristics**
• Four-quadrant linear operation with source and sink capability up to 100% rated current
• Output Impedance (Voltage Mode): 0.05 Ω series resistance, 5 mH series inductance
• Output Impedance (Current Mode): 100 MΩ shunt resistance, 0.3 µF shunt capacitance
• Peak-to-peak ripple measured over 20 Hz to 10 MHz bandwidth

## Key Features

• Dual-mode operation: voltage-stabilizing with adjustable current limiting and current-stabilizing with adjustable voltage limiting
• Independently adjustable voltage and current limits (programmable)
• FET output stage preamplifiers for summing and scaling arbitrary input signals
• Zeroable preamplifiers with minimum 20,000 V/V open-loop gain
• Uncommitted amplifier configuration available
• Natural convection cooling; optional forced-air cooling available

## Interfaces and Control

• Front panel local control with mode selection
• Remote programming via 30-terminal rear connector
• Separate control channels for output voltage and current

## Physical and Environmental

• Manufacturer: Kepco, Inc.
• Cooling: Natural convection (forced-air option available)
