Keysight (Agilent) 87302C Hybrid Power Divider, 0.5 GHz to 26.5 GHz

The Keysight (Agilent) 87302C is a hybrid power divider that splits input signals into two equal-amplitude outputs with minimal loss and high port isolation. Operating across 0.5 GHz to 26.5 GHz, it delivers insertion loss of 1.5 dB (0.5–18 GHz) and 1.9 dB (18–26.5 GHz) with 19 dB isolation between ports. The device maintains tight amplitude and phase tracking—critical for precision measurement and signal distribution applications where output consistency directly impacts test accuracy.

– Technical Specifications

Frequency Range: 0.5 GHz to 26.5 GHz

Insertion Loss (in addition to 3 dB coupling loss):
• 1.5 dB from 0.5 to 18 GHz
• 1.9 dB from 18 to 26.5 GHz

Isolation: 19 dB

VSWR:
• 1.45 (0.5–18 GHz)
• 1.60 (18–26.5 GHz)

Amplitude Tracking:
• 0.3 dB (0.5–18 GHz)
• 0.5 dB (18–26.5 GHz)

Phase Tracking:
• 6 degrees (0.5–18 GHz)
• 10 degrees (18–26.5 GHz)

Power Rating: 10 W continuous wave with 2:1 maximum load SWR

Connectors: 3.5 mm (SMA compatible)

Dimensions: 196.85 mm × 28.702 mm × 139.7 mm

Weight: 170 g

– Key Features

• Wideband operation from 0.5 to 26.5 GHz enables use across multiple RF bands
• Low insertion loss maintains signal integrity in cascaded systems
• Excellent port-to-port isolation minimizes cross-coupling effects
• Tight amplitude and phase tracking supports applications demanding matched outputs
• 10 W CW power handling suits moderate-power signal distribution and combining

– Typical Applications

• Signal distribution in test and measurement systems
• Signal combining networks
• RF/microwave component characterization
• Amplitude and phase-matched output requirements

– Compatibility & Integration

SMA-compatible 3.5 mm connectors provide direct integration with standard RF laboratory equipment and production test systems without adapter requirements.
