Keysight (Agilent) 8768M Multiport Coaxial Switch, DC to 50 GHz, SP5T

The Keysight (Agilent) 8768M is a single-pole, five-throw (SP5T) electromechanical coaxial switch operating from DC to 50 GHz. Built for high-performance signal routing in automated test environments, it delivers exceptional repeatability and insertion loss characteristics across its full frequency range. The switch safeguards test platforms against recalibration, downtime, and production losses—critical for communications and aerospace testing applications requiring reliable multiport switching.

– Technical Specifications

• Frequency Range: DC to 50 GHz
• Configuration: Single-pole, five-throw (SP5T) electromechanical design
• Impedance: 50 Ω
• Insertion Loss: Less than 3.0 dB at 50 GHz
• Repeatability: Less than 0.03 dB typical
• Connector Options:
– 2.4 mm (f) to 2.4 mm (f) standard (Option 101)
– 2.4 mm (f) to 2.4 mm (m) (Option 100)
• Solenoid Supply Voltage: 5 V (Option 011), 15 V (Option 015), or 24 V (Option 024)
• Calibration Certificate: Commercial calibration with test data available (Option UK6)

– Key Features

• 2.4 mm connectors support operation through 50 GHz with minimal signal degradation
• Five independent throw paths enable flexible multi-channel signal routing
• Electromechanical design provides long operating life and high cycle reliability
• Low insertion loss and tight repeatability ensure minimal test uncertainty
• Multiple voltage options (5 V, 15 V, 24 V) accommodate diverse control architectures

– Typical Applications

• Multi-port RF/microwave test and measurement
• Automated network analyzer and signal generator routing
• Communications system characterization and validation
• Aerospace test platform signal distribution
• High-frequency component and subsystem evaluation

– Compatibility & Integration

The 8768M interfaces with the Keysight 11713D/E Attenuator/Switch Driver for integrated control. Technical documentation, application notes on electromechanical switch performance and power handling, and STEP format 3D models are available for system design and integration.
