Keysight (Agilent) B2912B Precision Source/Measure Unit, 2-Channel, 10 fA

The Keysight B2912B is a 2-channel Precision Source/Measure Unit (SMU) engineered for high-accuracy sourcing and measurement of sensitive electronic components, devices, and materials. It combines voltage source, current source, voltage meter, and current meter functionality into a single compact instrument, reducing test setup complexity while maintaining measurement resolution as fine as 10 fA and 100 nV. The B2912B delivers 4-quadrant sourcing and measuring capabilities across a maximum output voltage of ±210 V and maximum DC current of 3 A (10.5 A pulsed), with 31.8 W output power.

– Technical Specifications

• Channels: 2
• Measurement & Source Resolution: 10 fA / 100 nV minimum
• Output Voltage Range: ±200 mV to ±210 V
• Output Current (DC): ±10 nA to 3 A; (Pulsed): up to 10.5 A
• Output Power: 31.8 W
• Resistance Measurement: 2 Ω to 200 MΩ (9-decade range)
• Display Resolution: 6½ digits
• Sampling Rate: Up to 100,000 Sa/s
• Minimum Timing Interval: 10 µs
• Buffer Memory: 100,000 measured values

– Key Features

• 4-wire measurement function eliminates cable resistance effects for precise low-voltage and low-resistance characterization
• High capacitance measurement mode prevents SMU oscillation with large capacitive loads
• Integrated arbitrary waveform generator (AWG) supporting up to 100,000 levels
• Sweep modes: Linear, Logarithmic, List
• 4.3-inch LCD color display (480×272 resolution) with graphical user interface—enables IV measurements without PC programming
• Multiple measurement modes: Single, Dual, Chart, Scroll, Graph, Roll View
• SCPI command compatibility for both conventional and default command sets

– Interfaces

• GPIB
• LAN
• USB 2.0 (2× ports: host and device)
• Digital I/O

– Software Support

Includes free PC-based control software: BenchVue, B2900 graphical web interface, B2900 Quick I/V measurement software, and Keysight EasyEXPERT group+.
