The Keysight E4310A is an Optical Time Domain Reflectometer (OTDR) mainframe designed for testing and troubleshooting optical fiber networks. It analyzes backscattered light to detect faults, measure fiber length, and assess signal loss within optical fiber infrastructure. The mainframe accepts user-exchangeable OTDR plug-in modules that determine specific optical testing capabilities and wavelength performance. Optional interfaces include HP-IB (Option 004) and LAN (Option 005) connectivity. The E4310A has been classified as obsolete by the manufacturer.
– Technical Specifications
• Product Type: Optical Time Domain Reflectometer (OTDR) Mainframe
• Manufacturer: Keysight Technologies (formerly Agilent)
• Model: E4310A (also designated 8147)
• Status: Obsolete
• Weight: Approximately 9 kg (20 lbs)
• Latest Firmware: Revision 4.3 (8147 Series)
– Key Features
• Modular architecture accommodates plug-in OTDR modules for flexible wavelength and performance configurations
• Multimode testing modules available for 850 nm and 1300 nm wavelengths
• Ultra high-performance 1625 nm modules available for WDM link testing
• Integrated optical power meter sub-module with measurement range from +10 dBm to −70 dBm
• Optional HP-IB and LAN interfaces for remote control and data acquisition
• Firmware upgradeable to Revision 4.3; firmware version accessible via Config softkey
– Typical Applications
• Optical fiber fault detection and localization
• Fiber length measurement and characterization
• Signal loss assessment in single-mode and multimode fiber networks
• WDM link testing and analysis
• 1625 nm fiber testing and validation
– Compatibility & Integration
The E4310A requires user-exchangeable connector interfaces such as the HP 81000×1 to operate. Compatible plug-in modules include the HP E6005A (multimode), HP E6010B, HP E6012A, HP E4321A, and HP E6060A (1625 nm ultra high-performance). Optional remote interfaces enable integration into automated test environments and network management systems.
