The Keysight E7515R UXM 5G Wireless Test Platform is a network emulator designed for testing Reduced Capability (RedCap) 5G NR devices, Cellular Internet of Things (CIoT) devices, and Narrowband Non-Terrestrial Networks (NB-NTN). Built on the proven architecture and software of the E7515B UXM 5G platform, it delivers RF, protocol, and functional testing across the complete device development lifecycle—from early design through certification, manufacturing, and repair.
The platform supports 5G NR RedCap in FDD, HD-FDD, and TDD modes, alongside CIoT, NB-IoT, Cat-M1, and LTE Cat-1 through Cat-4 technologies. Full 3GPP Release 17 compliance ensures devices meet current standards for RF performance, protocol behavior, and functional operation including IP data, voice, and battery characterization.
– Technical Specifications
• Frequency Range: 380 MHz to 3.8 GHz; 3.8 GHz to 6 GHz
• Aggregated NR Bandwidth: 100 MHz
• Bandwidth Option: 800 MHz
• RF Ports: 4 total—2 Downlink Transmit (TX) + 2 Uplink Receive (RX) @ 100 MHz bandwidth
• Interface: Baseband IQ (BBIQ)
• 3GPP Release Support: Release 17 (Rel-17)
• Testing Domains: Protocol, RF, and functional testing (IP data, voice, battery)
• Release 17 Features: Uplink coverage enhancements
– Key Features
• Optimized for 5G NR RedCap device characterization with reduced development and manufacturing costs
• Consistent hardware architecture and proven software as E7515B platform
• Full coverage across FDD, HD-FDD, and TDD RedCap modes
• Support for multiple cellular IoT standards in single platform
• Dual transmit and dual receive RF configuration for advanced testing scenarios
– Typical Applications
• Wearables
• Industrial sensors
• Smart home and city devices
• Security and surveillance systems
– Compatibility & Integration
The E7515R leverages the same validated architecture as the E7515B UXM 5G platform, enabling consistent workflows and software reuse across test environments. Baseband IQ interface supports direct device connection and RF stimulus/response characterization.
