The Keysight E5346A is a 34-channel single-ended Mictor connector probe kit that provides direct signal acquisition from target systems to compatible logic analyzers. It delivers 32 data channels and 2 clock channels with integrated RCR isolation networks, enabling accurate capture and analysis of complex digital signals while maintaining signal integrity and minimizing circuit loading across wide frequency ranges.
– Technical Specifications
Channel Configuration
• 34 total channels: 32 single-ended data channels + 2 single-ended clock channels
• Minimum signal amplitude: 500 mV peak-to-peak
• Equivalent load capacitance: 3.0 pF per channel
• Data rate equivalence matched to attached logic analyzer
Probe Interface
• 38-pin AMP Mictor (Matched Impedance ConnecTOR) connector
• RCR isolation networks integrated into cable end for signal conditioning
• High input impedance design minimizes circuit intrusion
• High transient noise immunity
Mechanical & Support
• Support shrouds available for board thicknesses up to 3.175 mm (0.125 in.)
• Shroud part numbers: E5346-44701 (up to 1.575 mm), E5346-44704 (1.575–3.175 mm), E5346-44703 (3.175–4.318 mm)
• Mictor connector part numbers: Keysight 1252-7431 / AMP 2-767004-2
• Connector kits supplied: 5 connectors and 5 support shrouds per kit
– Key Features
• Direct Mictor connector interface for on-board probe point integration
• Low capacitive loading (3.0 pF) suitable for higher-frequency analysis
• Integrated signal conditioning via RCR isolation networks
• Optional support shrouds with strain relief for mechanically demanding environments
• Selectable shroud options accommodate standard PCB thicknesses
– Typical Applications
• Digital system debugging and signal validation
• Multi-channel logic state and timing analysis
• Complex protocol capture and analysis
• In-circuit signal acquisition on production and development boards
– Compatibility & Integration
• Compatible with logic analyzers featuring 40-pin cable connectors
• Supported analysis modules: 16557D, 16710A, 16711A, 16712A, 16715A, 16716A, 16717A, 16718A, 16719A, 16750A, 16751A, 16752A
• Designed for direct board-level integration via Mictor connector footprint
