Keysight (Agilent) N6782A 2-Quadrant SMU

The Keysight N6782A is a single-channel, 2-quadrant Source/Measure Unit (SMU) engineered for advanced functional testing of semiconductor devices and power management circuits. Operating across ±6 V to ±20 V at up to ±3 A, the module sources and measures voltage and current with 0.025% + 1.8 mV programming accuracy on the 20 V range and 0.03% + 250 µA measurement accuracy on the 3 A range. The N6782A functions as a voltage or current source and as a Constant Voltage or Constant Current electronic load, delivering 20 W of output power in a single-slot form factor compatible with Keysight N6700C and N6705C modular power systems.

– Technical Specifications

• Voltage Output: ±6 V to ±20 V
• Current Output: Up to ±3 A (selectable 1 A, 3 A, 300 mA, and 10 µA ranges)
• Output Power: 20 W
• Voltage Programming Accuracy (23°C ± 5°C, 30 min warm-up): 0.025% + 1.8 mV (20 V range); 0.025% + 600 µV (6 V range)
• Current Programming Accuracy: 0.04% + 300 µA (3 A and 1 A ranges); 0.03% + 150 µA (300 mA range)
• Voltage Measurement Accuracy: 0.025% + 1.2 mV (20 V range)
• Current Measurement Accuracy: 0.03% + 250 µA (3 A range); 0.025% + 10 µA (100 mA range); 0.025% + 8 nA (10 µA range)
• Output Programming Speed: 10 µs transient response; 100 kHz modulation into resistive loads
• Digitizer: 200 kHz sampling rate; 5 µs measurement capture interval; 18-bit resolution (28-bit effective with autoranging)
• Over-voltage and Over-current Protection: Programmable

– Key Features

• 2-quadrant operation: source and load capability in single module
• Four current measurement ranges for precision across nA-to-A operating modes
• Patented Seamless Measurement Ranging technology eliminates glitches during autoranging transitions
• Fast AC modulation capability: waveforms up to 100 kHz for dynamic DUT stimulation
• High-speed digitized measurements capture power consumption every 5 µs
• Excellent transient response maintains voltage/current stability during rapid load changes

– Typical Applications

DC/DC converter testing, power management IC characterization, power amplifier load simulation, and power management unit functional validation.

– Compatibility & Integration

Designed for Keysight N6700C and N6705C modular power systems.
