Keysight (Agilent) U2054XA 10 MHz to 40 GHz USB Wide Dynamic Range Average Power Sensor

The Keysight U2054XA is a USB-connected average power sensor engineered for precise power measurements spanning 10 MHz to 40 GHz. It delivers a -70 dBm to +20 dBm measurement range with zero dead time real-time acquisition, capturing continuous pulse sequences without data loss. The sensor achieves measurement rates up to 50,000 readings per second, enabling high-throughput RF device characterization across radar, satellite communications, wireless systems, and modulated signal formats including GSM, WCDMA, LTE, and WLAN.

The U2054XA combines wide dynamic range performance with practical lab integration. Its 2.92 mm male RF connector accommodates standard test fixtures. Internal zeroing and automatic calibration routines minimize measurement uncertainty. Time-selectivity average mode with variable aperture duration allows flexible acquisition windows for transient and steady-state signal analysis.

– Technical Specifications

• Frequency Range: 10 MHz to 40 GHz
• Power Measurement Range: −70 dBm to +20 dBm
• Measurement Speed: Up to 50,000 readings per second; 1 M samples/sec variable sampling rate
• Real-time Measurement: Zero dead time for continuous pulse capture
• RF Connector: 2.92 mm male
• Interface: USB
• Calibration: Internal zero and automatic calibration

– Key Features

• Wide dynamic range for small-signal detection
• Time-selectivity average mode with variable aperture duration
• Built-in signal presets for radar, satellite, wireless, DME, GSM, EDGE, WCDMA, WLAN, LTE, and arbitrary modulated formats
• Bundled BenchVue software with Power Meter/Sensor Control and Analysis App (BV0007B)
• Includes 5 ft USB cable and dual 1.5 m BNC-to-SMB trigger cables
• Optional extended power sensor cables: 10 ft (Option 302) and 16.4 ft (Option 303)

– Typical Applications

• Radar system characterization
• Satellite communication link verification
• Wireless device manufacturing test
• Modulated signal power profiling

– Compatibility & Integration

Keysight BenchVue software provides instrument control, real-time data analysis, and automated measurement routines. USB connectivity enables direct integration into automated test systems and lab workstations.
