Keysight / Signametrics SMX2040 6.5-Digit PXI DMM Module

The Keysight/Signametrics SMX2040 is a 6.5-digit PXI Digital Multimeter module engineered for high-density automated test systems. This CompactPCI-compatible instrument delivers precise electrical characterization across DC/AC voltage and current, resistance, frequency, temperature, capacitance, inductance, and leakage measurements. The module integrates directly into PXI or CompactPCI chassis and connects to devices under test or switching cards with minimal integration overhead.

## Technical Specifications

**Measurement Functions**
• DC Voltage: mV to 330 V with 0.0045% basic accuracy
• AC Voltage: True RMS, 10 Hz to 100 kHz
• DC Current: Microamps to 2.5 A
• AC Current: True RMS measurements
• Resistance: 2-wire, 4-wire, and 6-wire guarded measurements up to 1 GΩ
• Frequency/Period: 1 Hz to 300 kHz counter function
• Temperature: RTD and thermocouple inputs
• Capacitance: DC and in-circuit AC measurements
• Inductance: Full measurement support
• Time: Duty cycle, pulse width, totalizer, and event counting
• Leakage: Dedicated measurement capability

**Performance**
• Resolution: 6.5 digits
• Reading rate: 1,000 readings/second
• DC Voltage accuracy: 0.0045%
• Isolation: Capable of measuring 300 VDC or 250 VAC, with floating signals up to 300 VDC or 250 VAC common mode

## Key Features

• Virtual front panel accessible via PC monitor for direct hands-on control
• Plug-and-play functionality eliminates complex initialization
• Measures floating or grounded signals without additional isolation hardware

## Typical Applications

Automated production testing, laboratory system integration, portable field measurement, high-density test benches requiring multiple measurement channels per chassis slot.

## Compatibility & Integration

Supports Windows 95/98, NT, 2000, XP, 2003, and Linux. Compatible with Visual Basic, C++, LabVIEW, LabWindows/CVI, TestPoint, ATEasy, Matlab, and VBA programming environments.
