Lake Shore 330

The Lake Shore 330 is an autotuning temperature controller for precise cryogenic and scientific temperature monitoring and control. It supports multiple sensor input types with dual sensor inputs for simultaneous data display, offering stable regulation down to 100 mK with control stability to ±2.5 mK. The instrument features five tuning modes, programmable PID parameters, and ten custom temperature zones, with temperature display in Kelvin, Celsius, or sensor units (V, mV, Ω). All measurements are NIST-traceable and each unit is tested to published specifications at shipment.

## Technical Specifications

• **Sensor Inputs:** Four model variants accommodate Silicon Diode (330-1X), Platinum RTD (330-2X), Gallium Aluminum Arsenide Diode (330-3X), and Thermocouple (330-4X) sensors
• **Temperature Range:** Operates down to 100 mK
• **Control Stability:** ±2.5 mK
• **Temperature Display Units:** Kelvin (K), Celsius (°C), Volts (V), millivolts (mV), Ohms (Ω)
• **Heater Output:** Linear output driver with current display on separate bar graph
• **Power Consumption:** Approximately 50 W
• **Dimensions:** 9 in. (W) × 4.5 in. (H) × 17 in. (D)
• **Weight:** 10 lbs

## Key Features

• Dual sensor inputs enable simultaneous monitoring of two sensors or one sensor with setpoint display
• Autotuning PID with five tuning modes and pre-programmed settings for rapid deployment
• Up to 10 programmable custom temperature zones for multi-stage temperature profiles
• NIST-traceable calibration and accuracy verified at shipment

## Typical Applications

Cryogenic materials research, dilution refrigerator operation, superconductivity studies, and low-temperature materials characterization requiring millikelvin-level stability.

## Compatibility & Integration

• IEEE-488 (GPIB) and RS-232C interfaces for remote operation and data acquisition
• Model 332 includes Model 330 command emulation for backward compatibility in existing software-controlled systems
