Rohde and Schwarz RT-ZD30 Active Probe, Differential, 0 Hz to 3 GHz

The Rohde & Schwarz RT-ZD30 is an active differential probe engineered for precision measurement of differential signals across DC and high-speed applications. Operating from 0 Hz to 3 GHz with a 110 ps rise time, this probe delivers exceptional signal fidelity while minimizing loading effects on the Device Under Test. Its dual attenuation factors (10:1 and 100:1) and high input impedance (1 MΩ || 0.6 pF) make it ideal for signal integrity analysis, high-speed data communication, and power electronics development. The probe incorporates DC offset compensation up to ±22 V and handles maximum input voltages of ±30 V, with inherent common-mode rejection for suppressing interference in noisy environments.

– Technical Specifications

Electrical Performance
• Bandwidth: 3 GHz
• Rise Time: 110 ps
• Attenuation Factor: 10:1, 100:1 selectable
• Input Impedance: 1 MΩ || 0.6 pF
• Input Capacitance: 0.6 pF
• Maximum Input Voltage: ±30 V (non-destructive)
• DC Offset Compensation: ±22 V (signal sockets to ground)
• Common-Mode Rejection: High
• Added Noise: Very low

Physical & Interface
• Cable Length: 1.2 m
• Probe Head Dimensions: Approx. 68 mm × 12 mm × 7.5 mm
• Connector: Rohde & Schwarz probe interface (7 mm BNC + pogo pins)

Environmental
• Operating Temperature: 0 °C to +50 °C
• Calibration Interval: 2 years

– Key Features

• Low DUT loading through high input impedance and minimal capacitance
• Switchable 10:1 and 100:1 attenuation for flexible gain selection
• Wide offset compensation range enables measurement of biased differential signals
• Comprehensive accessory kit: multiple probe tips, adapters, clips, and carrying case
• ProbeMeter and micro button for instrument control integration

– Typical Applications

• Signal integrity analysis in high-speed digital circuits
• Differential signal measurement in data communication systems
• Power electronics and switching circuit characterization
• Common-mode noise suppression in multi-layer PCB environments

– Compatibility & Integration

Designed for Rohde & Schwarz oscilloscopes with native probe interface compatibility. Confirmed compatible with RTM2032/34, RTM2052/54, RTO1002/04, RTO1012/14, and RTO1044 series instruments.
