The Rohde & Schwarz ESIB40 is a high-performance EMI test receiver and spectrum analyzer engineered for electromagnetic compatibility (EMC) testing across CISPR, EN, VDE, ANSI, FCC, BS, ETS, VCCI, MIL-STD, VG, and DEF-STAN standards. Compliant with CISPR 16-1-1, it combines receiver sensitivity with spectrum analyzer flexibility for product development from functional measurements through final certification.
– Technical Specifications
Frequency Coverage
• Input 1: 20 Hz to 40 GHz
• Input 2: 20 Hz to 1 GHz with integrated pulse protection
• Expandable to 110 GHz using external mixers (Option FSE-B21)
Sensitivity & Dynamic Range
• Noise figure: 10 dB typical
• Inherent noise: <-3 dBµV typical
• 1 dB compression point: +10 dBm
• Level display range: noise floor to 137 dBµV
• Measurement uncertainty: <1 dB up to 1 GHz
Resolution & Speed
• CISPR 16-1-1 resolution bandwidths: 200 Hz, 9 kHz, 120 kHz
• Analyzer mode: 1 Hz to 10 MHz selectable (-3 dB and -6 dB variants)
• Receiver and analyzer mode: 10 Hz to 10 MHz in decadic steps
• Minimum measurement time: 100 µs
Detection & Measurement
• Parallel detectors: up to 4 simultaneously
• Available detectors: Peak, Average, Quasi-Peak, CISPR Average, RMS
• Time-domain measurement resolution: 50 ns minimum
• Fast scanning in receiver mode; sweep capability in analyzer mode
Preselection & Amplification
• Fixed preselection in receiver mode; selectable in analyzer mode
• Three fixed-tuned and six or seven tracking filters (models 26 and 40)
• Integrated 20 dB preamplifier (selectable): 1 kHz to 7 GHz standard; option R&S ESIB-B2 extends to 40 GHz
Pulse Handling
• Input 2 withstands pulses up to 1500 V and powers up to 30 mWs (20 Hz to 1 GHz)
• Pulse weighting compliant with CISPR 16-1-1 and VDE 0876
– Key Features
• Dual-input architecture with dedicated pulse protection on Input 2
• Noise measurement, phase noise measurement, and channel power analysis
• Time-domain zero-span capability for transient analysis
• RF preselection positioned ahead of preamplifier for overload protection
– Typical Applications
Product EMC validation, conducted and radiated emissions testing, pre-compliance assessment, regulatory certification support, and broadband interference characterization.
