The Rohde & Schwarz NGPQ32/6 is a single-channel programmable DC power supply engineered for laboratory and test applications requiring precise, low-noise power delivery. Rated at 48 W maximum output, this linear-regulated supply delivers three independently selectable voltage/current ranges: 0–8 V / 0–6 A, 0–16 V / 0–3 A, and 0–32 V / 0–1.5 A. Voltage resolution reaches 1 mV, while current resolution spans 100 µA (6 A range) and 1 µA (100 mA range). Ripple and noise performance is specified at ≤0.6 mV RMS, with fast transient load response optimized for mobile communication device testing and battery simulation.
– Technical Specifications
• Output: 0–8 V / 0–6 A; 0–16 V / 0–3 A; 0–32 V / 0–1.5 A (multi-range)
• Maximum Power: 48 W
• Voltage Resolution: 1 mV
• Current Resolution: 100 µA (0–6 A range); 1 µA (0–100 mA range)
• Ripple & Noise: ≤0.6 mV RMS
• Regulation Topology: Linear
• Operating Modes: Constant Voltage (CV), Constant Current (CC), Foldback
– Key Features
• Configurable protection: Overcurrent (OCP/electronic fuse), overvoltage (OVP), overpower (OPP), and overtemperature protection
• Setable soft limits for voltage, current, and power with adjustable electronic fuse delay time
• Remote sensing capability for load-end voltage compensation
• Dual panel outputs (front and rear)
• Back-lighted LCD display for parameter setting, readout, and status monitoring
• Storage for up to 60 non-volatile system setups
• Electronic calibration support
• GPIB (IEEE488.2) and RS232 interfaces for remote instrument control
• Intelligent status indication
– Typical Applications
• Mobile device battery emulation and charger testing
• Sensitive component characterization requiring low-ripple supplies
• Production and development test environments demanding fast load transient response
• Automated test systems requiring programmable multi-range outputs
– Compatibility & Integration
Compact benchtop design with remote operation capability via GPIB and RS232 connectivity supports integration into automated test systems and laboratory setups.
