Rohde & Schwarz RT-ZC02 Current Probe, AC/DC, 0.01/0.001 V/A, 1000 A, 300 Vrms, 20 kHz

The Rohde & Schwarz RT-ZC02 is a Hall Effect AC/DC current probe engineered for non-intrusive measurement of steady-state, transient, and complex waveform currents up to 1000 A. The probe operates from DC to 20 kHz and delivers dual sensitivity modes (0.01 V/A and 0.001 V/A) to accommodate measurement ranges from 200 A to 2000 A, making it ideal for characterizing inverters, switch-mode power supplies, and industrial control circuits. Powered by a single 9 V alkaline battery, the RT-ZC02 connects via BNC to oscilloscopes and multimeters, requiring no circuit interruption during measurement.

– Technical Specifications

• Measurement Principle: Hall Effect technology
• Maximum Current: 1000 A
• Current Ranges: 200 A (0.01 V/A sensitivity) and 2000 A (0.001 V/A sensitivity)
• Bandwidth: DC to 20 kHz, –3 dB
• Rise Time: 5 µs (10% to 90%)
• Maximum Working Voltage: 300 Vrms (CAT III)
• DC Zero Error: ±100 mA
• Temperature Drift: ±0.15%/°C on sensitivity
• Noise Floor: 30 mA RMS (with 20 MHz low-pass filter); 80 mA RMS (unfiltered)
• Jaw Size: 32 mm
• Cable Length: 2 m
• Output Connector: BNC
• Power Source: 9 V alkaline battery (MN 1604)

– Key Features

• Dual sensitivity selection for extended dynamic range and measurement flexibility
• Fast 5 µs rise time suitable for switch transient capture
• Low zero-drift offset correction performed at the probe connector
• 32 mm jaw accommodates standard conductor sizes
• 2 m cable enables flexible test setup configurations

– Typical Applications

• Power inverter current profiling
• Switch-mode power supply commissioning and troubleshooting
• Industrial motor controller analysis
• Power semiconductor gate driver assessment

– Compatibility & Integration

The RT-ZC02 integrates directly with R&S RTH1000 and RTC1000/RTB2000 series oscilloscopes via predefined probe selection. BNC output enables connection to compatible oscilloscopes and multimeters across test environments. For high-frequency current measurement requiring 100 MHz bandwidth, the R&S RT-ZC20 variant is recommended.
