The Tektronix THS720P is a dual-channel handheld digital oscilloscope with integrated True RMS multimeter, engineered for field and bench troubleshooting in electrical and power electronics applications. It combines 100 MHz bandwidth, 500 MS/s sampling per channel, and isolated inputs rated to 600 VRMS CAT II, enabling simultaneous independent operation of oscilloscope and DMM functions. Advanced triggering—edge, pulse, video, and PWM motor drive—coupled with harmonic analysis to the 31st harmonic make it particularly suited for power quality assessment and motor drive diagnostics.
– Technical Specifications
Oscilloscope:
• 2 channels, 100 MHz bandwidth, 500 MS/s per channel
• 8-bit vertical resolution, 2500-point record length
• 5 mV to 50 V/div sensitivity (500 V/div with 10X probe)
• Time base: 5 ns/div to 50 s/div; roll mode ≥0.5 s/div
• ±10 div vertical position range, ±2% DC gain accuracy
• Acquisition modes: Sample, Envelope, Average, Peak Detect
• 8 ns glitch capture, Sin(x)/x interpolation
• Display formats: YT and XY; modes include Vector, Dot, Vector Accumulate, Dot Accumulate
• 2X, 5X, 10X vertical zoom
Triggering:
• Edge, Pulse, Video, and External trigger types
• PWM Motor Drive trigger (3- and 5-level pulse-width modulated signals)
• Video trigger with odd/even field and line selection
• Delay and Pulse advanced triggering
• 5 MHz TTL compatible external input
Digital Multimeter:
• 4000 counts, 3-3/4 digit resolution
• DC voltage: 400.0 mV to 880 V, ±(0.5% + 5 counts)
• True RMS AC voltage: 400.0 mV to 640 V, ±(2% + 5 counts)
• Resistance: 400.0 Ω to 40.00 MΩ
• Diode test, continuity check with audible tone at <50 Ω
• Datalogger included; Min, Max, Δ, Max-Min, Avg, Hold modes
Power Analysis:
• Harmonics measurement up to 31st harmonic (fundamental 30–450 Hz)
• Automatic power measurement with statistics
• Waveform math: Add, Subtract, Multiply, Watts calculation (V × I)
– Key Features
• Isolated dual channels for safe floating measurements
• True RMS multimeter integrated with real-time oscilloscope
• Specialized PWM motor drive trigger for inverter and drive testing
• Video and line-count triggering for sync signal analysis
• ±200 ppm horizontal accuracy
– Typical Applications
• Power electronics troubleshooting and commissioning
• Motor drive and inverter characterization
• Power quality and harmonic assessment
• Field service and bench verification
• Floating signal measurement in three-phase systems
– Compatibility & Integration
Supports 10X passive probes for extended voltage range to 500 V/div. External trigger accepts 5 MHz TTL-compatible signals.
