Wavetek 1362DMM

The Wavetek 1362DMM is a VXIbus card digital multimeter engineered for automated electrical testing and system integration. This instrument delivers precision measurement across DC voltage, AC voltage, and resistance with selectable resolution up to 6.5 digits. Full programmability via IEEE-488.2 and SCPI protocols enables direct integration into larger test systems and chassis architectures. External triggering with programmable delay and programmable external calibration ensure measurement integrity across extended operational periods.

– Technical Specifications

Measurement Ranges:
• DC Voltage: Five ranges, 100 nV to 300 V
• AC Voltage: Five ranges, 100 µV to 300 V
• Resistance: 100 Ω to 300 MΩ
• Resolution: Selectable 4.5 to 6.5 digits

Programmability and Control:
• VXIbus Compatibility: Standard Size C, VMEbus Functional Module with Interrupter capability
• Programming Interface: IEEE-488.2 (models 1362 and 1362MT); SCPI (model 1362S); CIIL compatible (1362MT)
• Trigger Control: External trigger with programmable trigger delay
• Calibration: Programmable external calibration (covers-on)

Line Frequency Configuration:
• Selectable operation: 50 Hz, 60 Hz, or 400 Hz via remote programming

– Key Features

• Message-based device utilizing VXIbus message transport
• Multi-range voltage and resistance measurement in single card form factor
• Programmable trigger delay for test synchronization
• Configurable line frequency to optimize ADC performance across global installations

– Typical Applications

• Automated test equipment (ATE) systems
• Production and functional testing
• Systems requiring integrated measurement within VXIbus chassis
• Applications demanding external trigger synchronization and programmable calibration

– Compatibility & Integration

The 1362DMM integrates into VXIbus chassis and systems as a Standard Size C VMEbus Functional Module. IEEE-488.2 and SCPI command sets provide cross-platform control. Model 1362MT additionally supports CIIL compatibility for legacy system integration.
