Wavetek 27XT

The Wavetek 27XT is a handheld digital multimeter engineered for electrical and electronic troubleshooting across industrial, field service, and maintenance environments. It delivers 11 functions across 32 measurement ranges, including AC/DC voltage, AC/DC current, resistance, capacitance, frequency, and inductance, plus diode and continuity testing. The 3.5-digit LCD with 0.7-inch characters and 2.5 Hz update rate displays measurements clearly in high-noise environments.

– Technical Specifications

Voltage Measurement
• DC: 200 mV to 1000 V across 5 ranges; ±(0.5% + 3 digits) accuracy; 10 MΩ input resistance
• AC: 200 mV to 750 V across 5 ranges; ±(1.0% + 5 digits) accuracy; 50 Hz to 1 kHz sine wave; 10 MΩ input impedance

Current Measurement
• DC: 200 µA to 20 A across 5 ranges; ±(1.0% + 5 digits) for 200 µA–200 mA, ±(2.0% + 5 digits) for 20 A; 100 nA resolution in 200 µA range
• AC: 200 µA to 20 A across 5 ranges; ±(1.5% + 5 digits) for 200 µA–200 mA, ±(2.5% + 5 digits) for 20 A; 50 Hz to 500 Hz; 100 nA resolution in 200 µA range

Resistance
• 200 Ω to 2000 MΩ across 7 ranges; ±(1.0% + 5 digits) for 200 Ω–2 MΩ, ±(2.0% + 5 digits) for 20 MΩ, ±(5.0% + 10 digits) for 2000 MΩ; 100 mΩ resolution in 200 Ω range; 3 V DC open circuit voltage (200 Ω, 2000 MΩ ranges), 0.3 V DC (other ranges)

Capacitance
• 0.1 nF to 4000 µF across 5–6 ranges; ±(5% + digits) accuracy

Frequency
• 10 Hz to 30 MHz; ±(0.5% + 3 digits) accuracy

– Key Features

• Data hold and max hold functions for capturing transient events
• Auto-power off extends battery service life
• Input warning beeper prevents measurement errors from reversed leads
• IEC1010-1 CAT II 1000 V and CAT III 600 V safety ratings

– Typical Applications

Field diagnostics, equipment maintenance, component verification, circuit troubleshooting, and preventive maintenance programs in industrial and commercial settings.

– Compatibility & Integration

Standard banana jack connectors. Operates on battery power with automatic shutdown to minimize replacement cycles.
