Wavetek 80320A

The Wavetek 80320A is a power sensor engineered for precise RF and microwave power measurement across a broad frequency spectrum. Operating from 10 MHz to 18 GHz, it delivers accurate readings from -60 dBm to +30 dBm with exceptional linearity and minimal VSWR across its operating range. The sensor integrates with leading power meters and network analyzers, making it suitable for both laboratory characterization and production test environments.

– Technical Specifications

Frequency & Power
• Frequency range: 10 MHz to 18 GHz
• Maximum power: +30 dBm (1 W)
• Power linearity: ±0.00 dB from -60 dBm to -10 dBm; ±0.05 dB/10 dB from -10 dBm to +30 dBm

Impedance & VSWR
• Characteristic impedance: 50 ohm
• VSWR (0.01 GHz – 2 GHz): 1.11
• VSWR (2 GHz – 12 GHz): 1.12
• VSWR (12 GHz – 18 GHz): 1.18

Connectors
• RF input: Type K(m), 50 ohm
• Type K connector is electrically and mechanically compatible with APC-3.5 and SMA connectors

– Key Features

• Excellent power linearity across dynamic range minimizes measurement uncertainty
• Low VSWR maintains signal integrity in critical measurement chains
• Type K connector with cross-compatibility reduces adapter requirements
• Available as used units with optional pre-shipment testing or new condition

– Compatibility & Integration

The 80320A interfaces with:
• Spanawave (formerly Giga-tronics) 8540B, 8540C, 8650A, and 8650B power meters
• 58542 VXI series power meters
• Giga-tronics 8540C Series Universal Power Meters
• Wavetek 8003 scalar network analyzer

This compatibility matrix positions the sensor as a versatile element in multi-vendor RF test systems.
