Wavetek LT8600

The Wavetek LT8600 is a high-performance LAN cable tester that validates network cabling systems to Category 6/Class E standards and beyond. It executes up to 15 individual tests or predefined test suites, delivering wire map, length, attenuation, NEXT, and advanced Power Sum measurements across a 300 MHz bandwidth. The instrument includes Time Domain Reflectometer (TDR) functionality—standard on LT8600T models—to locate faults, measure cable runs, identify embedded connectors, and display impedance versus distance in real time. Field-proven fast auto-test cycles minimize installation verification time, while onboard storage for 1500 results and LT-Record Manager software streamline documentation and certification workflows. The remote handset and integrated talkset enable efficient two-way communication during testing. UTP and STP cables are fully supported; optional FiberKit+ extends capability to single-mode and multimode fiber optic installations. An 8.4 V / 2.45 Ah NiMH battery delivers 8 hours of typical operating life per charge.

– Technical Specifications

• Frequency Range: Tests up to 300 MHz, exceeding Category 6/Class E limits
• Measurement Capabilities: Wire map, length, attenuation, NEXT, Power Sum NEXT, ACR, ELFEXT, and headroom—all up to 300 MHz
• Distance-to-Fault (DTF): Time Domain Reflectometer with real-time impedance plotting by wire pair; standard on LT8600T, field-upgradeable on legacy units
• Test Capacity: Up to 15 individual tests or suite configurations
• Data Storage: 1500 Auto-test results
• Battery: Rechargeable NiMH, 8.4 V / 2.45 Ah; 8 hours typical runtime
• Dimensions: 9.84 in (H) × 4.25 in (W) × 2.51 in (L); 1.76 lbs
• Operating Temperature: 0°C to 50°C

– Key Features

• Validates Gigabit Ethernet and 155 Mbps ATM infrastructure
• Remote handset and integrated talkset for field communication
• LT-Record Manager software for record keeping and certification reporting
• Serial I/O cable included for PC connectivity

– Compatibility & Integration

• Cable Types: UTP, STP, and fiber optic (with optional FiberKit+)
• Fiber Options: Single-mode and multimode; available with 850 nm multimode LED, 850/1300 nm dual-wavelength LED, or 1310/1550 nm single-mode laser modules
